ADS Speed Controller
The ADS design includes two pure analog frequency generators featuring low distortion and noise; a high current Class-A/B amplifier that is transformer-coupled to the turntable output; analog control logic for low noise operation; 33/45 RPM analog speed adjustment controls with center detent positions that are factory calibrated. Created by our previous Director of Electrical Engineering, Michael Bettinger.
Features
- Turntable Start Button
- Power on the Front
- Center Detent Knobs
- Easily Switch 33/45
The Machine
- The platter is started and stopped by the front panel Run/Stop momentary push button switch.
- The front panel contains a two-position push button switch for selecting either 33 RPM or 45 RPM operation.
- There are separate speed adjustment controls for 33 and 45 RPM.
- The controls have a detented center position that is factory calibrated for 60 Hz (33 RPM)
and 81 Hz (45 RPM). - The speed is continuously adjustable +/- 3 Hz
- Blue LED indicators adjacent to the controls indicate which speed is set at a glance.
Product Specifications
| Line Voltage | 115/230 VAC Factory set |
| Line Frequency | 50/60Hz |
| Line Fuse | 1 amp (Slo-Blo) |
| Output Voltage | 115/230 VAC Factory set |
| Start Voltage | 120/240 VAC |
| Run Voltage | 90/180 VAC |
| Output Frequency | 50Hz/60Hz Factory Set |
| Output Frequency Range | 60 Hz Center Detent: 60Hz @33 RPM & 81Hz@ 45 RPM 50 Hz Center Detent: 50Hz @33 RPM & 68Hz@ 45 RPM |
| Control Range | +/- 3Hz |
| Output Power | 15W |
| Dimensions | 16" x 4" x 12" (W x H x D) |
| Weight | 10lbs |
