PA 2000 R
The Integrated Amplifier
Building neat, compact integrated amplifiers offering high output power and superb sound quality is an art at which T+A has no peer. As proof of this claim we present the PA 2000 R integrated amplifier. It is incredibly dynamic, powerful and incisive. There are two reasons behind these characteristics: the extremely linear output stages with very low negative feedback, which are a completely new development, and the new form of mains power supply employed. We designed the latter specifically for audio devices, to ensure that they are ultra-stable under load, with no danger of collapse even when handling extremely high peak levels. The result is that the PA 2000 R can deliver a continuous power of more than 200 Watts per channel into 4 Ohms loudspeakers, enabling it to drive impedance-critical speakers whilst maintaining effortless control.
Technical Specifications
| Frequency response + 0 / −3 dB | 0,5 Hz – 300 kHz |
| Signal:noise ratio, unweighted/A-weighted | 105/109 dB |
| Total harmonic distortion/Intermodulation | < 0,001 % / < 0,001 % |
| Channel separation | > 90 dB |
| Loudness | Switchable, variable to suit loudspeaker efficiency |
| Loudness | Switchable, variable to suit loudspeaker efficiency |
| Tone controls Bass Treble | Switchable, channel-separate −6 … +8 dB −6 … +8 dB |
| Nominal input sensitivity | |
| High level (RCA) | 3 × 250 mV … 4 Veff/20 kOhms |
| Balanced (XLR) | 3 × 500 mV … 8 Veff/5 kOhms |
| Phono-MM (optional*) *Phono module replaces one high-level input | 1 – 5 mV, 16 Capacitances |
| Phono-MC (optional*) *Phono module replaces one high-level input | 60 – 1000 µV, 16 Impedances |
| Headphone | 50 Ohms |
| PRE out RCA | Nom 1 Veff, Max 9,5 Veff, 75 Ohms |
| Nominal output per channel | into 8 Ohms 100 Watts into 4 Ohms 200 Watts into 2 Ohms 300 Watts |
| Frequency response + 0/– 3 dB | 1 Hz – 150 kHz |
| Slew rate | 60 V/µs |
| Damping factor | > 65 |
| Total harmonic distortion | < 0,02 % |
| Reservoir capacity | 60000 µF |
| Control interface | R2-Link |
| Remote control | SRC 1 |
| Mains connection | 100 – 120 V oder 200 – 240 V, 50 – 60 Hz Max. 1000 Watts |
| Standby | < 0,5 W |
| Additional features | Trigger input +5V … 20V via adapter plug for remote power-on Input 3 (symmetrical) or 5 (asymmetrical) can be configured as Surround Pass Through |
| Optional Accessories | PHE-P/PA R MM or MC phono content_default | Power Three HD (Carbon) | Power Bar | Audio Quad (Carbon) | Speaker Hex (Carbon) |
| Dimensions (H x W x D) | 8,2 × 46 × 40 cm |
| Weight | 10,5 kg |
| Finishes | Silver anodised aluminium (43), black anodised aluminium (42), brushed |
